PW 760 Series

PVC WINDOW

Profile width 70 mm
Number of chambers 5
Profile class B Class (TS EN 12608-1)
Seal Type Internal-External, 2-seal system
Seal Type and Color TPE - Gray / Black
Glass thickness (mm) 4, 20, 24, 30, 32mm
The thermal insulation 1,45 W/m2K

Light Oak ST 515

Golden Oak ST 500

Anthracite Grey AS 508

Anthracite Grey ST 508

Swamp Oak ST 503

Grey ST 507

Dark Oak ST 501

Cream AS 057

Grey Sand AS 509

Mahogany ST 504

The main profiles have 70 mm width.

Because of the elastic grey and black seal which does not leave any stain on profiles will be provided maximum air, water, dust and sound isolation.

Due to the 5 chambers profiles, it has maximum performance for thermal, sound and water isolation.

It is a series of profiles with very special design that provides maximum wind resistance on high rise buildings.

In addition to white profile a different laminated color range is available.

4-5 mm single glazing application of 20, 24, 28, 32, 40, 42 mm glazing beads give us alternatives of using double, triple glazing and pane

PW 760 Series

just for your home

The PW 760 Series is designed to suit your life with its astonished water discharge system and aesthetic wing structure with gap.

While it can be applied to single glass (4-6mm) and double glazing (20-24-30-32 mm) with gray sealed glass laths in different thicknesses, TPE provides low inventory cost and rapid manufacturing option thanks to its gray and black sealed profiles.

Joinery production is available in any size you want, and you can produce as much as you want with the option of roller shutter (motor, remote control or manual) and without roller shutter.

Its 5-chamber system next to its 70 mm profile width, it provides excellent heat, sound and water insulation, while protecting against all seasonal conditions with its quality approved by national and international measurement institutions. While providing this protection, it also appeals to your eye taste with golden oak, dark oak, light oak, marsh oak, sand gray, gray, mahogany and cream colors.
